iSDT K2 Dual channel fast charge AC 200W / DC 2x500W 2x20A

alt

AC/DC dual mode

AC /DC dual input meet different use requirements. Output : AC /200W, DC /500Wx2.

alt

AC/DC Safe access

Fool-proof input interface. Smart design The DC input port and AC input port are mutually exclusive. Only one input can be selected in one time, Ensure the safety operation

alt

High Power Synchronous Dual Channel, with Smart Charging.

Smart High Speed Processor delivers parameter interfere to each port. Hassle Free with Maximum charging power up to 500W for single port. Choose ISDT, Powered by Innovation.

alt

2.8″ IPS LCD Display

Low power consumption, 178° visible angle Display clear and distinct Even in varies hard environment or angles As well as in strong sunshine.

alt

Two-way USB interfac

By connecting the charger microUSB port to the PC, all series can acquire latest firmware upgrading. It can also output 5V/2A power through the USB Type-C interface, For charging mobile devices.

alt


Package:



1. Charger iSDT K2
2. Power cord AC
3. Manual

Specifications:



Input voltage: AC 100~240V / DC 10~30V
Output voltage: DC 1~30V
Max. input current: DC 35A
Charging current: 0.2~20A x2
Discharging current: 0.2~1.5A x2
Balance current: 1.5A/Cell Max
Max. discharging power: 15W x2
Max. charging power: AC 200W / DC 500W x2
Abnormal voltage alarm: Support
Incorrect cell count setting alarm: Support
Supported battery types and cell count: LiFe, Lilon, LiPo 1~6S, LiHv 1-6S, Pb 1-12S, NiMH/Cd 1-16S
Parallel charging power and current: 800W/35A
Parallel discharge power and current: 30W/3A
Working temperature: 0~40℃
Storage temperature: -20℃~60℃
Dimension: 142x135x64mm
Weight: About 700g

INSTRUKCJA OBSŁUGI

Specifications

Input voltage: AC 100~240V / DC 10~30V
Output voltage: DC 1~30V
Max. input current: DC 35A
Charging current: 0.2~20A x2
Discharging current: 0.2~1.5A x2
Balance current: 1.5A/Cell Max
Max. discharging power: 15W x2
Max. charging power: AC 200W / DC 500W x2
Abnormal voltage alarm: Support
Incorrect cell count setting alarm: Support
Supported battery types and cell count: LiFe, Lilon, LiPo 1~6S, LiHv 1-6S, Pb 1-12S, NiMH/Cd 1-16S
Parallel charging power and current: 800W/35A
Parallel discharge power and current: 30W/3A
Working temperature: 0~40℃
Storage temperature: -20℃~60℃
Dimension: 142x135x64mm
Weight: About 700g
