Main Page1 » RC Radios ( Transmiters Receivers )2 » RadioLink RC6GS v3 2.4G 7CH Car Controller Transmitter + R7FG Gyro Inside Receiver for RC Car Boat
RadioLink RC6GS v3 2.4G 7CH Car Controller Transmitter + R7FG Gyro Inside Receiver for RC Car BoatRadioLink RC6GS v3 2.4G 7CH Car Controller Transmitter + R7FG Gyro Inside Receiver for RC Car BoatRadioLink RC6GS v3 2.4G 7CH Car Controller Transmitter + R7FG Gyro Inside Receiver for RC Car BoatRadioLink RC6GS v3 2.4G 7CH Car Controller Transmitter + R7FG Gyro Inside Receiver for RC Car Boat
RadioLink RC6GS v3 2.4G 7CH Car Controller Transmitter + R7FG Gyro Inside Receiver for RC Car BoatRadioLink RC6GS v3 2.4G 7CH Car Controller Transmitter + R7FG Gyro Inside Receiver for RC Car BoatRadioLink RC6GS v3 2.4G 7CH Car Controller Transmitter + R7FG Gyro Inside Receiver for RC Car BoatRadioLink RC6GS v3 2.4G 7CH Car Controller Transmitter + R7FG Gyro Inside Receiver for RC Car Boat
We recommend

RadioLink RC6GS v3 2.4G 7CH Car Controller Transmitter + R7FG Gyro Inside Receiver for RC Car Boat

RadioLink

Availability: Available in stock

Shipping time: 24 hours

The cost of shipping: from 3.26 Euro Available delivery forms for viewing the product:Curier Service - 4.19 Euro
Air Mail - 3.72 Euro
Poczta Polska list polecony - 3.72 Euro
Surface mail - 3.26 Euro
InPost Paczkomaty24 - 3.26 Euro
Personal Acceptance - 0.00 Euro

Producer code: RC6GS

Stockage:

Price: 78.14 Euro

Quantity: pcs.
Add to cart

add to wish list

  • Product description
  • Specyfications:
  • Product reviews (0)

RadioLink RC6GS v3 2.4G 7CH Car Controller Transmitter + R7FG Gyro Inside Receiver for RC Car Boat

alt




600 Meters Ground Distance


With the same FHSS spread spectrum of AT9S Pro and 67 channels, pseudo-random frequency hopping makes RC6GS V3 have the superior anti-interference ability both at the same frequency band and different frequency bands. With the transmitter chip of ARM M4 and the receiver chip as the industrial 32bits ARM Cortex M0, ensuring the superior ability of anti-sparks interference even enjoy with an oil tanker. The control distance is up to 600 meters.



alt



7 Channels for Multiple Types of Models


RC6GS V3 is an ideal partner for all types RC cars and boats in the market including single-engine and twin-engine models such as Crawlers, Tanks, Caterpillars, Basher, RC Short-Course Truck, RC Crawler, Drifting RC Car, Gasoline RC Car, Mini RC Car, RC Monster Truck, Off-Road RC Car, GP RC Car, EP RC Car, Sailboats, Trimaran, Bait Boat, Remote Controlled Lifebuoy, and other types of RC cars or boats.



alt



Real-time Built-In Telemetry of Model Battery Voltage

Telemetry is capable of RSSI, receiver, and model battery voltage. RSSI and receiver voltage data will display once binding complete. The model voltage will display by connecting the wire to the ESC, battery, and Telemetry port of receiver R7FG/R8F, no extra module needed. Telemetry of maximum 8S (33.6V) battery supported.



alt



Cruise Control System


Crawler is difficult in controlling the throttle on the downhill slope, the cruise control system of RC6GS V3 helps the driver easily set the optimal throttle volume for RC crawler car.



alt



Onboard Memory for 30 Models


RC6GS V3 can keep a maximum of 30 models parameters saved.





Subsidiary ID


RC6GS V3 is capable of an arbitrary ID designation among a maximum of 10 binding receivers, making long-distance rescue of RC cars or boats achievable





A switch can be set to active D/R

A switch/button can be set to operate D/R during the maneuvering of the car, it helps drivers quickly switch D/R during the 4-wheel drive session without having to go to LCD to press through all the menu each time.



alt



Dual Programmable Mix Control


7 channels transmitter. Arbitrary 2 channels can be easily set as mix control, easy to understand. For crawler: CH1 is the rudder, CH2 is the throttle, CH3 can set up to control the transfer case, CH4 can set up to control the shift gear, CH5 can set up to control the front locker, CH6 can set up to control the rear, and CH7 can set to control the capstan. For Timber Truck: dual programmable mix control makes front wheel mix with rear-wheel come true, which can reduce the turning radius.



alt



Multiple Function for DSC Port


The DSC port of RC6GS V3 can set as the Simulator Function(support VRC Pro,CarX, Assetto Corsa Competizione, and etc. simulators), the FPV Head Track Function(3-axis or 2-axis track can be selected), or the TBS Crossfire Function.



alt



FPV Head Track Function*



RC6GS V3 used FPV goggles to control the up, down, left, and right movement of the camera on the RC car. What's more, RC6GS V3 is compatible with TBS Crossfire by connecting it to the DSC port. Get more than 600 meters of controller distance by connecting to the TBS crossfire, and work with the FPV head track function to fully enjoy the funny of First-Person View of racing or crawl.



alt



Timer Function


The timer function of the RC6GS V3 allows you to grasp the lap and complete track results in time to help you train yourself before the race.



alt



Receiver with Gyro Integrated Customizable Gyro Sensitivity


Standard receiver R7FG packed is the receiver with built-in gyro and supports high voltage servo. It is anti-slip and keeps the uni-direction. With the integrated gyro in R7FG installed, the vehicle turns more smoothly, and drifting from high speed can be prevented. The easy setting ensures better control of gyro stabilization. Gyro sensitivity can be adjusted by STD or CH3 which is controlled by VR switch by default to maximize or minimize the gyro function.





Performance Upgrade: Ergonomically Designed for Hours of Fun


Base on the feedback of hundreds of experienced RC racers, we redesigned the throttle trigger, the thickness of the grip, and the location of each switch to achieve a better comfortable driving experience.
Rational throttle trigger length and tension, make easy and accurate for throttle adjustment. Threaded design helps antiskid when the drivers at the long-time practice or in hot weather.
A lanyard (comes with RC6GS V3) to make the suitable weight to highly compatible with drivers control habits make the long drive more pleasant.



alt



Water Splash Proof (IPX4) for Receiver R7FG


A receiver R7FG will packed with RC6GS V3. The PCB board and pins of R7FG have the same waterproof treatment as the mobile phone, that is, nano-coating technology treatment and the waterproof grade is IPX4. IPX4: The IP×× rating standard recommended by the International Electrotechnical Commission (IEC).



alt



Reverse Polarity Protection Circuit


RC6GS V3 is easily adapted for various battery layouts with wide operating voltage tolerance: 6pcs of AA batteries or 2S-4S LiPo or 18650 Lithium battery. Universal JST connector with the voltage protection software of Radiolink ensures vital components are protected from a reverse polarity connection. Pay attention: if you use a 18650 Lithium to power for RC6GS V3, please make sure the 18650 Lithium is with a JST connector and the dimension of the battery case is 89*59*25mm (3.5” *2.32” *0.98”).



alt

USB Upgrade


The RC6GS V3 is easily updating by the computer via a USB cable. Intuitive software hint guides you through the process. Note: The USB port only for upgrade, do not use it for charge.



alt



Wide Compatible


RC6GS V3 is packing with a receiver R6FG. RC6GS V3 is also compatible with the 4 channels mini receivers R4FGM/R4F designed for Mini RC cars, the 6 channels receivers R6F, the 7 channels receiver with gyro built-in, high voltage servo support, and model voltage telemetry support R7FG, and the 8 channels long control distance receivers R8EF/R8F, which designed for RC boats.



alt



Package:


- RC6GS V3
- R7FG
- Cable



alt




Specyfications:


Channels: 7
Control Distance: Up to 600 meters
Model: RC Cars and Boats
Low Voltage Alert: Yes(Below 4.6V)
Operating Voltage: 4.8-16.8V DC
Operating Current: 80mAh-120mAh
Screen: 128*64 resolution, LCD back light
Spread Spectrum: FHSS
Antenna Length: 106mm
Frequency: 2.4GHz ISM band (2400MHz-2483.5MHz)
Battery compartments: 25*97*60mm (JST 2Pin connector)
Size: 22.4*17.5*11.6cm
Weight: 323g
Compatible Receivers: Radiolink R7FG/R6FG/R6F/R4FGM/R4F/R8EF/R8F



Specyfications:


Kanałów: 7
Odległość sterowania: do 600 metrów
Model: samochody i łodzie RC
Alarm niskiego napięcia: tak (poniżej 4.6V)
Napięcie robocze: 4.8-16.8V DC
Prąd roboczy: 80mAh-120mAh
Ekran: rozdzielczość 128*64, tylne światło LCD
Widmo rozproszone: FHSS
Długość anteny: 106mm
Częstotliwość: pasmo ISM 2.4GHz (2400MHz-2483.5MHz)
Przedziały baterii: 25*97*60mm (złącze JST 2Pin)
Rozmiar: 22.4*17.5*11.6cm
Waga: 323g
Kompatybilne odbiorniki: Radiolink R7FG/R6FG/R6F/R4FGM/R4F/R8EF/R8F
