Producer code: 50010B
Stockage:
Special Features
1. Unique charge architecture realized better transient response to any changes of voltage on input and output.
2. The charger use advanced ADC measurement technology, high accuracy, high voltage and high current
detection circuit. The maximum voltage measurements tolerance is within 5mV at up to 10S LiPo battery.
3. The charger adopts advance balance circuit and Algorithm, constant 1.3A per cell balance current is very
useful for large capacity battery pack, the feature can resume all cell voltage balance status at the shortest
time. Over temperature protection make sure the system safety during balance.
4. Charger internal temperature protection. When the internal temperature exceeds the reduce temperature,
the output power is automatically decreased; and the charger will stop working when temperature exceeds
the shut-down temperature.
5. Intelligent fan control circuit sense internal temperature via temperature sensor, to thereby control the fan
speed.
6. TFT LCD screen provides rich information including current, voltage, power, capacity, time, working status
and temperature and so on.
7. The charger features a maximal safety protection,
Reversed polarity protection on input and output,
Anti-spark on input and output
Wrong battery pack connection protection when multi battery pack connected in series on adapter
board.
Charge time, charge capacity and battery temperature protection
8. Supports upgrading the firmware program by USB port.
Protection
Reversed polarity protection on input and output,
Anti-spark on input and output
Wrong battery pack connection protection when multi battery pack connected in series on adapter board.
Charge time, charge capacity and battery temperature protection
Specyfications:
1. Input voltage: DC 10-28V, 30V max.
2. Input Current: 25A maximal
3. Charge current: 0.1-20A, 500W max.
4. Discharge Current: 0.1-10A, 35W max.
5. Accuracy of the cell voltage: -5mV/+5mV
6. Balance current: 1.3A per cell only for LiPoly, Li-ion and LiFePO4 battery pack
7. Battery type: LiPo, Li-ion, LiFePo4, NiMh-NiCd, PB acid (VRLA)
8. Size: 154x114x33 (LxWxH mm)
9. Weight: 680g
